Pin 27 Black PCB Board Adapter Plate for BLTouch Filament Sensor Compatible With Creality CR-10/Ender 3/Ender-5 3D Print

Features ● This PCB board is black Works on BLTouch or filament detection sensor ● Improved design with wider power channels● With this adapter no wires need to be cut Simply connect this between your board and your cable attach the 3 bltouch wires and upgrade your firmware ● BLTouch is not included with the Pin 27 Board● Compatible with Ender 3 Ender 3 Pro Ender 5 CR 10 Mini CR 10 Incompatible with ANet A8 CR 8● You must have a Bootloader flashed to your Ender 3 Board in order to use this Using Note ● Disconnect lcd ribbon ext1 on the control board● Connect Ext1 to the pin 27 board● Connect bltouch to the 3 pins on the pin 27 board Left to right Brown Ground Red 5v Yellow Signal● Connect the pin27 to the main board Make sure to align the header pins from the pin 27 to the main board Installation instructions Click to know more Bootloader guide Clilck Ender 3 marlin guide Cllick no loss of Ender 3 marlin with bltouch Click no loss of Package Included 1 x Black Creality CR 10 Ender 3 Pin 27
