Parrot 6800mAh LiPo Smart Battery for ANAFI Ai Drone

The batteries' cells take advantage of the latest technology: high density associated to a high power delivery. The chemistry involved enables the raise of the charging electrical potential up to 4.4 V per cell.USB 3USB 3 standards internal electronics open a 600 Mb/s data transfer rate for the retrieval of photos and videos directly from the drone.Smart battery management systemThe battery is equipped with a gauge which measures in real time the battery's main parameters: voltage, current and temperature. Its internal algorithms enable the system to compute available energy in real time, based on these parameters and on the cells' "state of health".The precision of this estimate is the basis of the "Smart RTH" function: the battery provides the information which enable the drone to determine the energy necessary to return to its take-off point safely.Smart chargingWith its embedded 45 W charger, ANAFI Ai's battery can be charged easily and quickly through any USB-C adapter. The battery is 3.0 USB-PD (Power Delivery) compatible. This protocol enables a full charge in 150 minutes.The charging power is automatically adapted to ambient temperature to avoid damaging the cells.WinteringAfter 10 days inactivity (no charge nor flight), the battery automatically discharges itself to 60% charge - its optimal storage charge - and switches to wintering mode.This mode guarantees the battery an optimal state of storage: it stops all current leakage by isolating the cells from the electronic circuit. This prevents cells from reaching a tension level which would deteriorate the chemistry of the battery (3 V). Therefore, batteries can be safely stored for a full year.Batteries exit the wintering mode when plugged to a power source.Black BoxEquipped with an internal memory, the battery saves the history of its measures (charge/discharge cycles, state of health) and transfers them to FreeFlight 7. This data can also be exploited by Parrot Support services for enquiries in case of malfunction.USB-C "OTG" interfaceThe USB port of the battery can provide 2 A power to an external peripheral as a 4G key, a C02 detector, or any kind of USB-equipped electronic device.PowerbankThe battery can be used as an emergency charger for any kind of electronic device (smartphone, tablet).Charge indicatorThe four LED of the battery indicate the battery's level of charge in the following situation:• battery in charge• power button activated• battery installed on ANAFI Ai and drone powered onThe state of charge is an expression of the energy remaining in the battery, by quarters of the total energy the battery can store.Quality• Parrot is ISO9001 certified.• Batteries are UN38.3 certified for transportation.• Batteries are CE and FCC certified.• Quality control process:• Parrot has implemented a reinforced quality control process for battery manufacturing (audit of suppliers, IQC controls) and set up test benches for each step of the assembly process• Parrot performs random X-ray and tomography controls on samples, to check the quality of the cells (folding, connectors).• If users choose to share their data with Parrot, their ANAFI Ai batteries' state of health is transferred to Parrot's cloud for support and statistics purposes.
