PW300S 300Mbps In-Wall Wireless Access Point - Silver

PW300S is a stylish in-wall WiFi Access Point, which is specially designed for existing building structure, without affecting the appearance of the interior design. The design can provide users with convenient wireless local area network (WLAN). The PW300S is designed with standard 86 x 86 mm European Outlet Box size and can be installed in the existing building structure to easily construct a wireless network. Thus, it helps system integrator save time, cost and human resource. It is a best-in-class 802.11n indoor access point designed specifically for business-class environments such as hotels, airports, coffee shops, shopping centers, sporting venues, and university campus Integrated Power over Ethernet (PoE) allows installation in areas where power outlets are not readily available.
Features
European 86 type wall outlet compatibility Design
600Mhz MTK7620N RF Chipset, 802.11b/g/n Support.
32MB SDRAM + 4MB Flash Build-in for Higher Performance.
Gateway / Wireless Client / AP operation modes.
Passive 24V PoE supports up to 70 meter (200 feet) deployment.
Central AP Control Management Software Support.
Specifications
Wireless
Standards
IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate
300Mbps
Frequency Band
2.4~2.4835GHz
Wireless Transmit Power
11n MCS7:19±1dBm 11g 54Mbps:19±1dBm11b 11Mbps:20±1dBm
Receive Sensitivity
11N MCS0@-83dBm; MCS7@-65dBm 11G 54Mbps@-82dBm; 6Mbps@-95dBm 11B 11Mbps@-85dBm; 1Mbps@-95dBm
Operation Mode
Gateway, Repeater(Extender), AP(access point)
Wireless Security
64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements
Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, IOS
Hardware
Interfaces
2 x RJ-45 for 10/100 Mbps(One for POE)
MCU
MTK7620N
SDRAM&FLASH
32MB+4MB
Button
1 x Reset button(Reset & Factory Defaults)
LED Indicator
WiFi, Power, System
Antenna
2 x built-in 2dBi omni-directional Antenna
Power Supply
POE 24V
Software
Wireless Function
Distance Control (802.1x Ack timeout), Multiple SSID (4 SSID) BSSID
Security
WEP Encryption-64/128/152 bit WPA/WPA2 Personal (WPA-PSK using TKIP or AES)WPA/WPA2 Enterprise (WPA-EAP using TKIP) Hide SSID MAC/IP Address &URL filtering Wireless STA (Client) connected list
DHCP
DHCP Server, DHCP Client
Network
Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
Management
Firmware Upgrade and backup, factory Reset, Restart, WEB
Product Size
86 x 86 x 30 mm
Product Weight
100g
Package Size
12 x 12 x 7 cm
Package Weight
250g
