PROMO TERASIC VEEK-MT2 THE VIDEO AND EMBEDDED EVALUATION KIT - MULTI-TOUCH, SECOND EDITION

PRODUK PRE-ORDER
- Tidak bisa cancel setelah order dikonfirmasi.
- Estimasi waktu pre-order sekitar 15-30 hari, tergantung dari lamanya pengiriman.
- Kami bisa bantu klaim garansi ke distributor, namun Invok Lab tidak dapat menanggung biaya kirimnya. Diterima atau ditolaknya klaim garansi adalah 100% keputusan dari distributor.
- Produk TERASIC dijamin original karena kami ambil barang langsung dari official distributor luar maupun dalam negeri.
- Kami juga melayani konsultasi dan pengadaan komponen, sensor, dan lain-lain untuk proyek elektronik anda.
Terasic VEEK-MT2 The Video and Embedded Evaluation Kit - Multi-touch, Second Edition
The Video and Embedded Evaluation Kit - Multi-touch, Second Edition (VEEK-MT2) is a comprehensive design environment with everything embedded developers need to create processing-based systems. VEEK-MT2 delivers an integrated platform that includes hardware, design tools, intellectual property (IP) and reference designs for developing embedded software and hardware platform in a wide range of applications. The fully integrated kit allows developers to rapidly customize their processor and IP to best suit their specific application. The VEEK-MT2 features the DE2-115 development board targeting the Cyclone IV E FPGA, as well as a capacitive LCD multimedia color touch panel which natively supports 5 point touch and multi-touch gestures. A 8-megapixel digital image sensor, ambient light sensor, Gyroscope, Magnetometer, and 3-axis accelerometer make up the rich feature-set.
Cyclone IV EP4CE115 FPGA
114,480 logic elements (LEs)
432 M9K memory blocks
3,888 Embedded memory (Kbits)
266 Embedded 18 x 18 multipliers
4 General-purpose PLLs
528 User I/Os
Configuration
EPCS64 serial configuration device
On-board USB-Blaster circuitry
JTAG and AS mode configuration supported
Memory Devices
128MB SDRAM
2MB SRAM
8MB FLASH with 8-bit mode
32Kbit EEPROM
Switches and Indicators
18 switches and 4 Push-buttons
18 red and 9 green LEDs
Eight 7-segment displays
Audio
Character Display
16x2 LCD module
On-board Clocking Circuitry
Three 50MHz oscillator clock inputs
SMA connectors (external clock input/output)
SD Card Socket
Provides SPI and 4-bit SD mode for SD card access
Two Gigabit Ethernet Ports
172-pin High Speed Mezzanine Card (HSMC)
Extension for LCD and camera module
Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V)
USB Type A and B
Provides host and device controller compliant with USB 2.0
Support for data transfer at full-speed and low-speed
PC driver available
40-pin Expansion Port
Configurable I/O standards (voltage levels: 3.3/2.5/1.8/1.5V)
VGA-out Connector
VGA DAC (high speed triple DACs)
DB-9 Serial Connector
RS-232 port with flow control
PS/2 Connector
PS/2 connector for connecting a PS/2 mouse or keyboard
Remote Control
Infrared receiver module
TV-in Connector
TV decoder (NTSC/PAL/SECAM)
Power
12V DC input
Switching and step-down regulators LM3150MH
Capacitive LCD Multi-touch
