PROMO SEEED STUDIO RECOMPUTER J3010-EDGE AI DEVICE WITH NVIDIA JETSON ORIN NANO 4GB MODULE

PRODUK PRE-ORDER
- Tidak bisa cancel setelah order dikonfirmasi.
- Estimasi waktu pre-order sekitar 15-45 hari, tergantung dari lamanya pengiriman.
- Produk SEEED STUDIO dijamin original karena kami ambil barang langsung dari official distributor luar maupun dalam negeri.
- Kami juga melayani konsultasi dan pengadaan komponen, sensor, dan lain-lain untuk proyek elektronik anda.
reComputer J3010 is a hand-size edge AI box built with NVIDIA Jetson Orin™ Nano 4GB module which delivers up to 20 TOPS AI performance and has a rich set of IOs including USB 3.2 ports(4x), HDMI 2.1, M.2 key E for WIFI, M.2 Key M for SSD, RTC, CAN, Raspberry Pi GPIO 40-pin and more. It is also equipped with an aluminum case, a cooling fan with a heatsink, and a pre-installed JetPack System. As part of the NVIDIA Jetson ecosystem, reComputer J3010 is ready for your next AI application development and deployment.
Jetson Orin Nano System on Module
AI Performance
reComputer J3011, Orin Nano 8GB - 40 TOPS;
reComputer J3010, Orin Nano 4GB - 20 TOPS
GPU
1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores (Orin Nano 8GB);
512-core NVIDIA Ampere architecture GPU with 16 Tensor Cores (Orin Nano 4GB)
CPU
6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3
Memory
8GB 128-bit LPDDR5 68 GB/s (Orin Nano 8GB);
4GB 64-bit LPDDR5 34 GB/s (Orin Nano 4GB)
Video Encoder
Video Decoder
Carrier Board
Storage
M.2 Key M PCIe (M.2 NVMe 2280 SSD 128G included)
Networking
Ethernet
M.2 KEY E
1x M.2 Key E(pre-installed 1x Wi-Fi/Bluetooth combo module)
I/O
USB
4x USB 3.2 Type-A (10Gbps), 1x USB2.0 Type-C (Device Mode)
CSI Camera
2x CSI (2-lane 15pin)
Display
1x HDMI 2.1
Fan
1x 4 pin Fan Connector (5V PWM)
CAN
1x CAN
Multifunctional Port
RTC
RTC 2-pin, supports CR1220 but not included
Power Supply
9-19V DC
Mechanical
Dimensions (W x D x H)
130mm x 120mm x 58.5mm (with case)
Installation
Desk, wall-mounting
Operating Temperature
-10℃~60℃
OS
Pre-installed Jetpack 5.1.x (above) (provide Linux OS with board support package)
Certification
FCC, CE, RoHS, UKCA
Sebelum di kirim barang sudah di pastikan bagus dan tanpa kerusakan apapun.
