PLC Programmable Controller PLC Control Board Output Current: 5A 8000 Steps RS232 For Conversion Circuit Protection Electricity Control Circuit

PLC Programmable Controller PLC Control Board Output Current: 5A 8000 Steps RS232 for Conversion Circuit Protection Electricity Control Circuit Specification: Features: Input point X x0-x7 DC24 input low valid. X0-5 is the high-speed counting input port default: 12K 100KHZ optional. Output analog voltage WR3A instruction corresponding to the value 0-4095. The maximum speed current is 1A. External load common terminating + 24 the other end received the PLC output port Y. Y0-Y5 is optional relay or transistor output relay output current 5A. The transistor output DC24V the current maximum 1A. Intermediate relay M: M0-M3071 the power loss preservation range can be set. Specification: Weight: 239g/8.4oz Input point:8 Output point:6 Power supply voltage: DC24V Output current: 5A Analog input: 6AD Analog output: 2DA High speed count:6 road 12K optional 100K Pulse output: No Floating point: Support Step motor: No support Memory capacity:8000 step Programming software: GX developer or GX works Program steps: 8000 steps Two communication ports: One RS232 DB9 serial communication port is FX3u protocol 38400 7 E 1; One RS485 485 optional configuration communication protocol can be set to D8120. The output point Y : Y0-Y5 is optional relay or transistor output relay output current 5A. The transistor output DC24V the current maximum 1A. Y0-1 is high-speed output port maximum 100K. PWM period is 0-32767US. High The maximum speed current is 1A. External load common terminating + 24 the other end received the PLC output port Y. Analog input: Six-way analog input 12 bit accuracy input voltage:0-10V 0-20MA; Read the analog quantity with RD3A directive. The corresponding values 0-4095. Two-way potentiometer analog input D8030 D8031. Analog output: 2-channel analog output 12-bit accuracy output voltage: 0-10v. Output analog voltage WR3A instruction corresponding to the value 0-4095. Intermediate relay M: M0-M3071 the power loss preservation range can be set. Step point S: S0-1023 power off storage range can be set to S0-S1023 100Ms timer: t0-t199 accumulative power off save t184-t199 10Ms timer: T200-T249 accumulative power off saving T246-T249 1Ms timer: T250-T383 where T250-255 is cumulative 16-bit counter: C0-C199 power off to save C100-199 32-bit counter: C200-C219 power off to save C220-C234 32-bit high-speed counter: C235-255; C235-240 is a single-phase counter not frequency doubling; C241-240 is a single-phase counter with double frequency; C247-249 is a two-phase counter not frequency doubling; C250-252 is a two-phase counter with double frequency; C253-255 is a two-phase counter 4 times frequency; Register D: D0-D7999 power off save range can be set to d0-7999 Indirection pointer V Z: V0-7 Z0-7 P subroutine number: P0-63 I interrupt: X0-5 external interrupt. Timer interrupt 1MS. The counter is interrupted. Special M components: M8000 is normally closed when running M8002 is electric pulse M8011 is 10Ms pulse M8012 is 100Ms pulse M8013 is 1s pulse M8014 is minute pulse. Package List: 1x PLC Control Board
