PHABRIX PHQXL01-3G 1U HD/2K 10GbE IP/SDI Rasterizer with One Analyzer Module

The Qx Physical Layer Toolset is a factory fitted option for fast 12G/6G/3G/HD-SDI physical layer commissioning, testing and development. Its RTE (Real-Time Eye) Technology instantly highlights any SMPTE compliance issues and its realtime SDI jitter window provides simultaneous monitoring across five specified frequency bands, jitter histogram and video trigger options.You can receive accurate measurements within seconds of connecting an SDI signal. The unit enables you to measure both rise and fall overshoot at the top and bottom of the waveform. In addition, the unit displays amplitude, rise and fall overshoot delta and DC offset - all compulsory measurements when testing against SMPTE standards. The unit highlights any measurements exceeding the specification (for example, an eye amplitude greater than 10 %) in red.Built-in automation control allows testing to be performed faster, more reliably and at lower cost.SDI Eye Analysis• Real-Time Eye (RTE) for testing SMPTE compliance with indication of DC offset• Automatic measurements of: DC level, amplitude, rise and fall time, rise/fall overshoot, visual rise time indication• Horizontal time histogram of eye crossing point (0 mV threshold)• Vertical amplitude histogram indicating energy distribution across all samples• Single or multiple eyes with choice of color, heat-map overlay and infinite persistence• Timing and Alignment jitter thermometers, color-coded according to the analyzed SDI standard
