PD132 Single Channel Inductive Vehicle Loop Detector for FAAC BFT CAME Gate Barrier Operator

Features : Reset Switch: The reset switch enables the detector to be manually reset during registering and testing and it is a process of system recovery; Selectable Pulse Time: This feature sets the length of time that the pulse relay will be lasting for 1 Second or 0.5 Seconds; Pulse Relay Selection: The Pulse Relay may be configured to energize on detection of a vehicle or when the vehicle leaves the loop; Sensitivity Reinforcement: This feature sets the un-detecting level to a maximum sensitivity to prevent failing to detect vehicles as big trucks; Switch Sensibility Adjustable: 4 sensitivity setting are available on the switches to change sensitivity; Switch Frequency Adjustable: 4 frequency settings are available to prevent signal interference with neighboring loops; Filtering Option: This option is used to provide a delay between detection of the vehicle and switching of the output relay. This relay is normally used to prevent false detection of small or fast moving objects; Permanent Presence Option: This feature ensures the detection of the vehicle will be maintained when the vehicle stays within the loop area for extended periods. Specification : Supply voltage: 110V AC / 220V AC / 12V DC / 24V DC Voltage tolerance AC: +10% / -15% Voltage tolerance DC: 15% Power Consumption: 4.5VA Operating temperature: -20 to +65 Storage temperature: -40 to +85 Frequency range: 20 kHz to 170 kHz Reaction time: 10ms Signal lasting time: Unlimited / limited when loop is permanently covered 10 minutes Sensitivity: Adjustable Loop inductance: Total loop plus connection wiring: 50H to 1000H; Ideal is 100H to 300H Loop connection wiring: Maximum length 20 meters, twisted at least 20 times per meter Dimension: 78x40x108 mm (L x W x H) Package includeds : 1 x Vehicle Loop Detector (110V AC / 220V AC / 12V DC / 24V DC for Optional~) 1 x User Manual >>>Download Wiring Diagram
