Original JYETech DSO138 DIY Digital Oscilloscope Kit Electronic Learning Kit

Note: This is the newest version 13804K (113-13801-050). This is a DIY kit, need to have some basic electronic activity and ability, because of different levels of ability and technical, we can not guarantee that everyone can DIY success, but we are committed to do our best of after-sales service. Product Documents and firmwares: (click to open) Users Manual [for 13801K/02K(discontinued)] Users Manual [for 13803K/04K] Assembly Drawing Surface Mount Component Installation Guide SMD Part List Firmwares Source codes [basic version] DSO138 Library How to Use the DSO138 Library Schematic of the LCD board How to Upgrade firmware for DSO138 Features: Kits using ARM Cortex-M3 processor (STM32F103C8) and includes a 2.4-inch color TFT display can be used as ARM test development board. Available source, Capable people can be secondary development on the basis of the suite, for example, it can be changed to Millivoltmeter, data loggers, and so on (we don't supply any technical support about that). Circuit is simple and the kit is inexpensive Description: PCB size: 117 x 76mm Screen size: 52 x 40mm Supply voltage: DC 9V Characteristics of indicators: Maximum real-time sampling rate: 1Msps Accuracy: 12Bit Sampling buffer depth: 1024 bytes Analog bandwidth: 0 - 200KHz Vertical Sensitivity: 10mV / Div - 5V / Div (1-2-5 progressive manner) Adjustable vertical displacement, and with instructions Input impedance: 1M Maximum input voltage: 50Vpp (1: 1 probe) 400Vpp (10: 1 probe) Coupling modes: DC / AC / GND The horizontal time base range: 10s / Div - 50s / Div (1-2-5 progressive manner) With automatic, regular and one-shot mode, easy to capture the moment waveform Available rising or falling edge trigger Adjustable trigger level position, and with instructions Observable previous trigger waveform (negative delay) Can freeze at any time waveform display (HOLD function) Comes 1Hz /3.3V square wave test signal source Package included: 1 x DIY Digital Oscilloscope Kit Test, for reference only:
