Original JYETech DSO138 DIY Digital Oscilloscope Kit 13804K Version With Acrylic Housing

Note SMD is unsoldered and without instruction about how to solder the SMD This is an unassembled kit customers should have some basic electronic activity and ability because of different levels of ability we can not guarantee that everyone can DIY success but we are committed to do our best of after sales service Product Documents and firmwares click to open Users Manual for 13801K 02K discontinued Users Manual for 13803K 04K Assembly DrawingSurface Mount Component Installation GuideSMD Part ListFirmwaresSource codes basic version DSO138 LibraryHow to Use the DSO138 LibrarySchematic of the LCD boardHow to Upgrade firmware for DSO138Features Kits using ARM Cortex M3 processor STM32F103C8 and includes a 2 4 inch color TFT display can be used as ARM test development board Available source Capable people can be secondary development on the basis of the suite for example it can be changed to Millivoltmeter data loggers and so on we dont supply any technical support about that Circuit is simple and the kit is inexpensiveDescription PCB size 117 x 76mmScreen size 52 x 40mmSupply voltage DC 9VCharacteristics of indicators Maximum real time sampling rate 1MspsAccuracy 12BitSampling buffer depth 1024 bytesAnalog bandwidth 0 200KHzVertical Sensitivity 10mV Div 5V Div 1 2 5 progressive manner Adjustable vertical displacement and with instructionsInput impedance 1MMaximum input voltage 50Vpp 1 1 probe 400Vpp 10 1 probe Coupling modes DC A
