Orange Pi Plus 2 H3 Quad Core 1.6GHZ 2GB RAM 4K Open Source Development Board Mini PC

Description: - What's Orange Pi Plus 2? It's an open-source single-board computer. It can run Android 4.4 Lubuntu, Debian, Rasberry Pi Image It uses the AllWinner H3 SoC, and has 2GB DDR3 SDRAM - Who's it for? Orange Pi Plus 2 is for anyone who wants to start creating with technology not just consuming it. It's a simple, fun, useful tool that you can use to start taking control of the world around you. - What can I do with Orange Pi Plus 2? You can use it to build A computer A wireless server Games Music and sounds HD video A speaker Android Scratch Pretty much anything else, because Orange Pi Plus is open source Hardware specification CPU H3 Quad-core Cortex-A7 H.265/HEVC 4K GPU Mali400MP2 GPU @600MHz Supports OpenGL ES 2.0 Memory (SDRAM) 2GB DDR3 (shared with GPU) Onboard Storage TF card (Max. 64GB) / MMC card slot 16GB EMMC Flash Onboard Network 10/100/1000M Ethernet RJ45 Onboard WIFI Realtek RTL8189ETV, IEEE 802.11 b/g/n Video Input A CSI input connector Camera: Supports 8-bit YUV422 CMOS sensor interface Supports CCIR656 protocol for NTSC and PAL Supports SM pixel camera sensor Supports video capture solution up to 1080p@30fps Audio Input MIC Video Outputs Supports HDMI output with HDCP Supports HDMI CEC Supports HDMI 30 function Integrated CVBS Supports simultaneous output of HDMI and CVBS Audio Output 3.5 mm Jack and HDMI Power Source DC input, USB OTG input don't supply power USB 2.0 Ports Four USB 2.0 HOST, one USB 2.0 OTG Buttons Power button: Next to Reset button UBoot button (optional): Behind HDMI connector Low-level peripherals 40 Pins Header,compatible with Raspberry Pi B+ GPIO(1x3) pin UART,ground. LED Power led & Status led Key IR input,UBOOT,POWER Supported OS Android, Lubuntu, Debian, Rasberry Pi Image Interface definition Product size 108mm 67mm Weight 52g Power supply 5V 3A Operating Temperature -10 ~ 65 Orange Pi is a trademark of the Shenzhen Xunlong Software CO. Limited Notes: 1. Number will change at any time, affected by the offline stores and local procurement 2. It is best to buy a good quality DC 5V/3A charger . Because Orange Pi doesn't support Micro USB Power supply. Orange Pi requires a memory card beyond 8g, class10 Click for more info Package included: 1 x Orange Pi Plus 2
