Octpeak RF Module Broadband 0.1‑3000MHz 32dB High Gain Low Power Microwave Ham 9‑12V RF Ham RF 0.1‑3000MHz

Feature: 1. GOOD CURRENT PASSING: Excellent printed circuit board adopt 1.6mm thickness double sided board full tinning process guarantee good passing performance of large and small currents 2. WITHOUT BURRS: One piece molding without burrs bring simple installation very useful and practical 3. GOOD HEAT DISSIPATION: RF module come with large area heat dissipation which can guarantee run a longer time 4. SCRATCH RESISTANT ABS: RF adopt ABS material possess impact resistance scratch resistance environmentally friendly 5. RECEIVER FRONT END: Especially suitable various RF receiving front end circuits to extend the communication distance very versatile Specification: Item Type: RF Module Material: PCB Operating Frequency: 0.1-3000MHz Working Voltage: 9-12V Working Current: 27mA Amplification Gain: 32dB(typ.) F=0.1MHz gain=32dB F=500Mhz gain=32dB F=1000MHz gain=32dB F=1500Mhz gain=32dB F=2000MHz gain=32dB F=2500MHz gain=30dB F=3000MHz gain=29dB Maximum Output: 13dBm (20mW) System Impedance: 50ohms Connector Model: SMA K RF In: Input signal amplification RF Out: Output amplified signal VCC: Positive power supply (suitable lithium batteries) GND: Negative power supply Package List: 1 x RF Module Note: Pay attention to the correct operation.
