Octpeak RF Microwave Mixer Board Good Isolation Double Balanced Mixing Frequency Converter Module Frequency Mixer Module RF Double Balanced Mixer

Feature: 1. DIFFERENTIAL CIRCUIT: Both frequency inputs are applied to the differential circuit so neither the input signal nor the product signal appear at the output. 2. DOUBLE BALANCED: This mixer module is more complex than unbalanced and single balanced mixer with good stability requiring higher drive levels. 3. GOOD ISOLATION: The mixer module has good isolation at the RF and IF ends relative to the LO end so the requirements for the IF filter are not high. 4. HIGH PERFORMANCE: The RF input is 1.5‑4.5GHz IF output is DC‑1.5GHz and the frequency conversion loss is small with low noise and less interference. 5. EASY TO INSTALL: The double balanced mixer module has compact size with standard mounting holes for easy installation and does not take up space. Specification: Item Type: RF Mixer Board Material: PCB RF Input: 1.5-4.5GHz IF Output: DC-1.5GHz Conversion Loss: 8.5dB Noise Figure: 8.5dB (SSB) Local Oscillator Input: 13dBm Port Isolation: LO to RF: 40dB (typical) LO to IF: 35dB (typical) High Input 1P3: 18dBm High Input P1dB: 8dBm Package List: 1 x RF Mixer Board Note: Pay attention to the correct operation
