Octpeak PM2.5 Sensor Dust Haze Sensor G5 PMS5003 Laser PM2.5 Sensor Air Quality Monitoring Dust Haze Tester

Features: 1. Laser scattering principle achieves accurate measurement. 2. Constant wind pressure and self-adaption control system. 3. Optical system adopts high performance laser module and photosensitive components. 4. Adopt deep algorithm to optimize the compensation ensuring that the measuring results under different environment are stable and consistent. 5. Same-side air inlet and outlet simplify structural design. 6. Dust prevention sensor structure design. 7. The product has gone through EMI testing and passed reliability testing. Specification: Model G5 PMS5003 Effective range 0~500ug/m3 Maximum range 000ug/m3 Resolution of PM concentration 1ug/m3 Minimum Dia. of distinguishable PM 0.3um Consistency of PM2.5 concentration (25±5)℃ (50±10)%RH standard testing environment ±10% @ 100~500ug/m3 ±10ug/m3 @ 0~100ug/m3 Response time ≤3s Data interface [email protected] PWM Interface level Input voltage for high level(VIH): 1.8V~5V Input voltage for low level(VIL): 2.9V Output voltage for low level(VOL): 30000 hours Package List: 1 * Laser PM2.5 Sensor
