OWON HDS2202/HDS2202S 2CH Handheld Oscilloscope 200MHz Bandwidth 20000 Counts Multimeter OSC + DMM + Waveform Generator

Please click here to download the English manual and softwareModelHDS2202HDS2202S Bandwidth 200MHz200MHz Channels 2 CH Oscilloscope2 CH Oscilloscope 1 CH Generator Sample Rate 1GSa s Specifications Oscilloscope ModelHDS2202HDS2202S Bandwidth 200MHz200MHz Channels 2 CH Oscilloscope2 CH Oscilloscope 1 CH Generator Sample Rate 1GSa s Acquisition Model Normal Peak TestRecord Length8KDisplay3 5 inch LCDWaveform Refresh Rate10 000 wfrms sInput Coupling DC AC and Ground Input Impedance 1 MΩ 2 in parallel with 1 6pF 10pF Probe Attenuation Factors 1X 10X 100X 1000X 10000XMax input Voltage400V DC AC PK PK 1MΩ input impedance 10 1 probe attenuation Bandwidth Limit typical 20MHz Full bandwidthHorizontal Scale 2ns div 1000s div step by 1 2 5 Vertical Sensitivity 10mV div 10V div Vertical Resolution 8 bits Trigger Type Edge Trigger Modes Auto Normal single Automatic MeasurementFrequency Period Amplitude Max Min Mean PK PK Cursor Measurement△V △T △T△V between cursors Communication InterfaceUSB Type C Multimeter Standard Max Resolution20 000 countsTesting ModeVoltage Current Resistance Capacitance Diode and Continuity testInput Impedance10MΩMax Input VoltageAC 750V DC 1000VMax Input CurrentDC 10A AC 10ADiode0 2V Waveform Generator Only for HDS242S HDS272S HDS2102S HDS2202S Frequency OutputSine0 1Hz 25MHzSquare0 1Hz 5MHzRamp0 1Hz 1MHzPulse0 1Hz 5MHzArbitrary0 1Hz 5MHzSampling Rate125MSa sChannel1 CHAmplitude Range high impedanc
