NuMicro ICP programmer Nu-Link Nuvoton ICP Emulator Downloader Support Online/Offline Programming M0/M4 Series Chips
Eachine1
sku: 1440646
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$14.59
Shipping from: China
Description
Features: - In-Circuit programming target chip - Online/offline programming mode - Backup flash data of target chip (If the target chip is not flash protected) - Backup offline flash data of Nu-Link dongle (if offline data has been unprotected) - Write software serials number (SN) to target chip - Limit the maximum programming count - Data encryption for online/offline programming - Batch mode for online/offline programming Preparing for ICP Programming Tool: 2.1 System Requirements The hardware and software requirements for installing the ICP Programming Tool system are as follows: PC/AT compatible machine with Pentium or higher CPU XVGA(1024*768) color monitor At least 512M RAM for best performance At least 20M free disk space Windows 2000/XP/Vista/7 2.2 Hardware Installation Step 1: Plug USB cable into the USB port of the ICP Programming Tool board. Step 2: Connect the ICP Programming Tool board with ICE interface of DEV board. 2.3 Software Installation Please run the installer package to install the software Operation Modes of ICP Programming Tool and Nu-Link Dongle: 3.1 ICP Programming Tool Modes The ICP tool supports "online" and "offline" programming mode. 3.1.1 Online Programming Mode If the "Offline programming mode" option in Figure 4-14 is unchecked, ICP Programming Tool will program in online programming mode. Click the "Start" button in Figure 2-2 to start to program target device immediately. The target device must be connected to Nu-Link. 3.1.2 Offline Programming Mode If the "Offline programming mode" option in Figure 4-14 is checked, the ICP Programming Tool will program in offline programming mode. Click the "Start" button to save the file data into Nu-Link at first, no matter a target device is connected to Nu-Link or not. Package Included: 1 x ICP Emulator Downloader Support Online/Offline Programming
