NanoPi R1 Dual Ethernet Port IoT Router Allwinner H3 512MB/1GB RAM with USB & Serial Port Router

Specifications CPU Allwinner H3 Quad core Cortex A7 Up to 1 2GHz DDR3 RAM 512MB 16 bit 1GB 32 Bit Storage NC 8GB eMMC Network 10 100 1000M Ethernet x 110 100M Ethernet x 1 WiFi 802 11b g n with SMA antenna interface Bluetooth 4 0 dual mode USB Host Type A x2 MicroSD Slot x 1 MicroUSB for OTG and power input Debug Serial Port 3Pin 2 54mm pitch pin header UART 4Pin 2 54mm pitch pin header LED LED x 3 PC Size 50 5 x 60mm Power Supply DC 5V 2A Temperature measuring range 20℃ to 70℃ OS Software U boot Ubuntu Core OpenWRTIntroduction The NanoPi R1 R1 is a complete open source board developed by FriendlyElec for makers hobbyists fans and etc The NanoPi R1 has one Gbps Ethernet port and one Fast Ethernet port It has an onboard 2 4G Wi Fi module FriendlyElec ported OpenWRT to the R1 With some additional settings it will work like a router Its good networking performance and features make it a good platform for various network applications Package Including 1 x Nanopi Ri Assembled 1 x Micro USB Cable
