NTXF4-FC Omnibus F4 Flight Controller OSD Integrated 5.8G 48CH PIT/25/100/200/400/600mW VTX 5V BEC
![NTXF4-FC Omnibus F4 Flight Controller OSD Integrated 5.8G 48CH PIT/25/100/200/400/600mW VTX 5V BEC](http://imgaz.staticbg.com/images/oaupload/banggood/images/A2/28/f9eb1f2a-b5c8-44f4-86c8-3a7f7d9661f0.jpg)
Eachine1
sku: 1286961
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$42.55
Shipping from: China
Description
NTXF4-FC Omnibus F4 Flight Controller OSD Integrated 5.8G 48CH PIT/25/100/200/400/600mW VTX 5V BEC Specification: User Manual, DOWNLOAD Item name: NTXF4-FC Firmware: betaflight_3.2.0_OMNIBUSF4SD Processor: STM32F405RGT6 Sensor: MPU6000 OSD video overlay: AT7456E 5.8G transmission picture transmission: 600MW 48CH six transmission power adjustable (PIT, 25MW, 100MW, 200MW, 400MW, 600MW) Image transmission antenna interface: MMCX antenna base (feeder with distribution to SMA needle) Receiver interface: DSM and IBUS, PPM, SBUS LED_Strip interface BB ring/buzzer interface Voide INPUT connector (5V) SD card black box (self-provided SD card) Reserved UART1, UART3, UART6 interface LC filter Built-in 5V 3A BEC Supply voltage: 2-6S (7.4V-25.6V) ESC signal support Dshot, Oneshot, Multishot, PWM Board size: 36x36MM Hole spacing 30.5x30.5MM Board weight: 8.7 g Package Included: 1 x NTXF4-FC Flight Controller 1 x 8P*1.0MM plug wire 2 x 3P*1.0MM plug cable 8 x M3*5+6MM nylon column 4 x M3*5MM screw cap 1 x MMCX-SMA Feeder
