NTE Electronics CFC-2/4 - CAPACITOR CEILING FAN 2+4 UFD 125/250 VAC 3 WIRE

The NTE CFC series is a range of metallized polyester film capacitors designed expressly for ceiling fan use. They are a self-healing flat capacitor winding with polyester film dielectric. They are mounted in a flame-retardant plastic case with an epoxy resin end-seal. The CFC series are also used in other electric fans and in fluorescent lamps. Technical Specifications Small size and light weight High insulation resistance and small dissipation factor Capacitance range: 3 wire 125/250VAC - 2/4 °fd to 6/14 °fd Operating temperature range: -25°C to + 70°C Insulation resistance (at 20°C): Between Terminals: ≥ 1000MΩ Insulation resistance (at 20°C): Between Terminals and Case: ≥ 2000MΩ Case dimensions (HxWxD): 1.141x1.535x0.748
