NOYAFA NF-901 High Quality Optical Fiber Light Source for CATV Communication 2 Wavelengths Output 1310/1550nm

Features 1 Work with NF 900 optical power meter 2 A fast stable and cost effective test solution 3 Provide 2 wavelengths output 1310 1550nm 4 CW 270Hz 1KHz 2KHz modulation output 5 FC SC ST general purpose interface Product description Provides steady light source and work with optical power meter Wavelength nm 1310 1550 Emitter type FP LD Output power 7dBm Modulation frequencies CW 270Hz 1Hz 2Hz Fiber Type SM MM Optical connector FC included SC FC LC is optional Automatic shutdown time 15mins Power supply 1 5V 3pcs Overall dimension 160 x 75 x 32 mm Working temperature 10 50 0 to 95 percent RH no condensing Storage temperature 20 70 0 to 95 percent RH no condensing Specification Model NF 901Wavelenth nm 1310 1550Emitter typeFP LDOutput power 7dBmModulation frequenciesCW 270Hz 1Hz 2HzFiber TypeSM MMOptical connectorFC SC FCAutomatic shutdown time15minsPower supply1 5V 3pcsOverall dimension160x75x32mmPackage includes Optical fiber meter x1 Battery not included User manual x1Clean cotton swabs x1bagCarrry bag x1Color box x1Details picture
