NEW! 20 Plate Water to Water Plate Heat Exchanger 1 & 3/4 FPT Ports W/Brackets

NEW! 20 Plate Water to Water Brazed Plate Heat Exchanger withInstall Brackets. (2)-1 & (2) 3/4 FPT Ports 80 000 BTU * GPM 3.5 * 1” and ¾” FPT Ports * Dimensions – 5”x12”x2” * Pressure Drop 3.5 These are true 5 x 12 Units if hooking up to an indoor boiler do not settle for anything smaller in width or length. These are made of 316 Stainless Steel and are UL listed do not settle for ones made of 304 stainless. These are an expensive item and no reason to have to replace them sooner thanneeded. Not to be used for transferring steam! We provide a lifetime warranty against manufacturer s defects and 3 yearson corrosion. Any questions feel free to email us or call us at 888-591-0943 Dealer inquiries welcomed. Brazed plate heat exchanger Plate material: stainless steel AISI 316L Brazing material: Copper 5x12 plate specs Max pressure 652 lbs per sq in Test pressure 971 lbs per sq in Volume per channel (L) 0.05 Exchange area sq ft. .417 per plate Max Temperature 437F These are used for transferring heat from one hot water source to another without mixing the two different water sources. For example when hooking up a non pressurized furnace to an indoor boiler or for heating cold water before it goes into the hot water heater to eliminate the need for fuel to power your water heater. They are good for preheating water to waterheaters and for transferring heat from an outdoor furnace or solar system to an indoor boiler. Other uses for them include transferring heat from hot oil or cooling milk off a milk pipeline. Sizingyour plate depends on several factors. Plates have BTU ratings of approximately 4 000 BTU per plate ie a 10 plate is40 000 BTU and a 40 plate is 160 000 BTU.
