N76E003AT20 51 Development Board Nu-Link N76E003 Development Board

Download method You can directly program the program through the USB cable or you can use the usb to serial port for serial communication Onboard high speed USB to serial communication chipCPU Fully static 8 bit 1T 8051 core CMOS microcontroller The instruction set is fully compatible with MCS 51 Level 4 priority interrupt configuration Double Data Pointers DPTRs Working conditions Wide voltage operating range from 2 4V to 5 5V Wide operating frequency up to 16MHz Industrial operating temperature 40C to 105C Memory Up to 18K bytes of APROM user program code area Configurable 4K 3K 2K 1K 0K byte LDROM boot code area for flexible user configuration All FLASH areas are separated by 128 bytes Built in IAP programming function Code encryption 256 bytes of on chip direct access to RAM Additional 768 bytes of on chip indirect access RAM XRAM read and write via MOVX instructions Clock source 16 MHz high speed internal oscillator with 1 accuracy rating at 5 0V supply Full working condition range2 accuracy level 10 kHz low speed internal oscillator Support for external clock input Support system clock real time software switching On the fly function Support software configuration clock divide by up to 1 512 Features Up to 17 standard universal pins plus one pin that can only be used as input All output pins can be configured with two output slopes via software Package includes 1 x N76E003AT20 Development Board1 x USB cable
