N2201SS Antenna analyzer N1201SA Upgraded version 137.5~2700MHz High Accuracy Meter Resistance/impedance/SWR/S11

Please click here to download the English manualDescription English verison N2201SS UV RF Vector Impedance ANT SWR Antenna Analyzer Meter Tester 137 5 2 7HMz resistance impedance SWR This instrumenthasfour interfaces single point measurement scanning system information correction and calibrationThe default boot into single point measurement interface The N1201SA adds a power meter 20dBm 8dBm accuracy 1dB input power 0dBm 8dBm It is for small power and micro power communicatin device testing If you use it on large power machine you need extra coupler or attenuator Note For the convenience of the user each time calibration correction options will automatically change to the user calibration Meanwhile in order to ensure the integrity of the calibration the calibration process the automatic shutdown function fails the consistent boot N1201SS analyzer Specifications Frequency 137 5MHz 2700MHz Spacing 1kHz Display 2 4inch TFT Pixel 320 240 QVGA Battery 2000mAH 7 4Wh Power dissipation 1 5W Charging current 400mA Charging port Mini USB Micro USB For charging only Auto Power Off Adjustable Always on 5mins 60min Measure facts resistance reactance SWR s11 Resolution ratio 4bits effective digits Frequency accuracy ±10ppm Connector SMA K Directivity 25dB 2GHz 2 7GHz 35dB 140MHz 2GHz After calibration
