Mppt Solar Charge Controller 12V 24V Auto Battery Regulator 30A Max Lcd Display

Feature *Advanced MPPT maximum power point tracking technology charge controller with tracking efficiency is no less than 99.5%. *High quality components solar charger the maximum conversion efficiency can reach 97%. *Super fast maximum power tracking speed controller while ensuring tracking efficiency. *Accurate identification and tracking of the maximum power point of multi-wave peak. *Reliable maximum input power of PV array to ensure the safety of equipment. *12 24v AUTO voltage identification wide PV array maximum power point operating voltage range. *The charger s LCD is designed to dynamically display the operation data and working status of the equipment. *Various load control modes: general mode light control mode dual-time mode pure charger mode and timing mode. *Lead-acid and lithium charging processes can be selected. *Dual USB port charging Specification Product name: MPPT SOLAR charge controller Item model number: keeper-1230 Rated Charge Current: 30A System rated voltage: 12V/24VAuto work Voltage range of battery: 8-32V Max open voltage of PV module: 75V Battery Type: User default Sealed Flooded GEL LiFePO4 Equalized charging voltage: Maintenance-fee lead acid battery 14.6V GEL: No; Lead acid flooded battery: 14.8V Absorption charging voltage:Maintenance-fee lead acid battery 14.4V GEL:14.2; Lead acid flooded battery:14.6V Floating charging voltage: Maintenance-fee lead acid battery GEL Lead acid flooded battery: 13.8V Low voltage re-connection(LVR): Maintenance-fee lead acid battery GEL Lead acid flooded battery: 12.6V Low voltage disconnection(LVD): Maintenance-fee lead acid battery GEL Lead acid flooded battery: 10.8V Static loss: ≤9.2mA 12V; ≤11.7mA24V High voltage disconnection (HVD): 16V (24V×2) Duration of absorption charging: 2 Hours Light control voltage: 5V Charge loop voltage drop: ≤0.29V LCD Temperature: -20℃~+70℃ Operating Temperature: -20℃~+55℃(To run at full rated current continuously) Working humidity: ≤95% No condensation Protection class: IP30 Dimension(LxWxH)mm: 133×195×55 Installation hole size(LxW)mm: 116×140ȼ5 NOTE: The controller will start PWM function at high voltage disconnection (HVD) voltage point which limits voltage rising to protect battery. Packing list: 1*mppt solar controller 1*Instruction
