Motor Driver Controller PWM Signal 73x51x37mm Regulator Board -12V/15-160V PWM Regulator Simple Reliable

Description: This module is supplied as a drive signal. To control the motor but also must have the drive to use. The controller has high medium and low total of three types of frequency signals can be used to select . Frequency of measurement can amount PUL and common cathode terminal (GND) two . PUL + and PUL- d positive and negative; EN + and EN- is to enable the positive and negative terminals; DIR + and DIR- are the positive and negative directions. These six lines are connected to drive the corresponding direction so six possible. The forward and of the motor can be controlled by pressing the key. the speed of the motor can be controlled by adjusting the frequency of the potentiometer. Specification: Material: : 15-160VDC or 5-12VDC. If you are using 5-12VDC power positive end connect -12V Input negative end connect Common Cathode End. Frequency: High: 5.8KHZ-127KHZ Mid: 590HZ-15.8KHZ Low: 82HZ-2.3KHZ Size Chart: 73x51x37mm/2.87x2.01x1.46inch Package Includes: 1x PWM Signal Note: 1. Please allow slightly error due to manual measurement. 2. Due to the difference between different monitors the picture may not reflect the actual color of the item. 3. Wish you a wonderful shopping!
