Monport Lightburn-ready 20 x 28 la/ser Engraver & Cutter with FDA Appro W13

Monport la/ser Engarver & Cutter 20 x 28 with Manual FocusMonport 60W la/ser Engraver & Cutter 20 x 28 with Manual Focus Working Dimension: 20 x 28 ( 50 cm x 70 cm ) Machine Dimension: 49.2” x 36” x 36.2” (125cm x 91.5cm x 92cm） Maximum Engraving Speed: 600mm/s Maximum Cutting Speed: 400mm/s ( actual speed depends on material ) Max Engraving Depth: 10mm Min Engraving Depth: 0.01mm Focal Lens Diameter: 18mm Mirror Diameter: 25mm Package Dimension: 52.8 x 44” x 44.6 ( 134 cm x 112 cm x 113.5 cm ) 10” Standard Z-depth and 11” Max Z-depth Net Weight: 319.7 lbs ( 145 kg ) Package Weight: 387.1 lbs ( 171.5 kg ) Software Works on Windows XP 2000 Vista WIN 7 8 10 & 11 both 64 & 32 bit MacOS (Version 10.11 and higher) ONLY with LightBurn software Compatible with Lightburn RDWorks Coreldraw Auto-CAD Supported image formats: BMP HPGL GIF JPG JPEG DXF DST AI and others la/ser System la/ser Wavelength 10640 nm; Rated at over 60 watt; Recommended engraving speed: 100 - 500mm/s Recommended cutting speed: 1 - 30mm/s (actual speed depends on the thickness of material) Mechanics Linear System— Enclosed aeronautical aluminum rails Motion— Equipped with stepper X Y axis plus mechanical limit switches Cooling— Easy-to-setup water pump and hoses Air Assist— Built-in air assist with no external compressor required Ventilation— On-board exhaust fan as well as an exhaust hose so you can vent the fumes to the outdoors Standard 110V AC power connection 4-pin port connection for rotary axis devices Temperature Recommended Operating Temperature: 60-104 °F (16C-40C) Attention: the water temperature must be maintained at 60-70°F (16-21°C) 60W la/ser tube with an estimated lifetime of up to 2 000 operation hours depending on power setting usage and water cooling performance PLEASE NOTE: Frequent use of high la/ser power settings will shorten the la/ser tube lifetime as follows: Low Power 10–40% = 1 700–2 000 Hours Moderate Power 40–70% = 1 300–1 500 Hours High Power 70–100% = 800–1 000 Hours Can safely engrave or cut any la/ser-compatible material Wood glass acrylic fabric leather paper cardboard rubber Contact us with questions on specific materials not listed. If necessary we can test it for you la/ser Engraver Machine *1 Water Pump *1 Storage Tank *1 Ethernet to Ethernet Cable *1 USB Type-A to Type-A Cable *1 Venting Exhaust Duct (4 ft. max. length) *1 Water Hoses *2 USB Drive with Software (RDworks) *1 Hex Wrenches *10 Double-sided Tape *1 Power Cord *2 Accessory Bag *1 Keys *2 Silicone Sealant *1 Instruction Manual *1 Stainless Steel Clamp *1 2 year warranty on all 60W la/ser machines and parts 6 month warranty on 60W la/ser tubes FDA Approval & CE Certified
