Monport LightBurn 24 x 36 la/ser Engraver Marker Engraving Mach D69

Machine Dimension: 57 x 43 x 35 (145cm x 110cm x 90cm ) Package Dimension: 61” x 47” x 43” ( 155 cm x 120 cm x 110 cm ) Working Dimension: 24 x 36 ( 61 cm x 91.5 cm ) Pass-through Dimension: 2.9 x 37.4 （7.5cm x 95 cm ) Max Engraving Speed: 600mm/s Max Cutting Speed: 30mm/s ( actual speed depends on material ) Max Engraving Depth: 19.05mm Min Engraving Depth : 0.01 mm Focal Lens Diameter: 18mm Mirror Diameter: 25mm 7” Standard Z-depth and 8” Max Z-depth Net Weight: 396.8 lbs ( 180 kg ) Package Weight: 529.1 lbs ( 240 kg ) Software Works on Windows XP 2000 Vista WIN 7 8 10 & 11 both 64 & 32 bit MacOS (Version 10.11 and higher) ONLY with LightBurn software Compatible with Lightburn RDWorks Coreldraw Auto-CAD Supported image formats: BMP HPGL GIF JPG JPEG DXF DST AI and others la/ser System la/ser Wavelength 10640 nm; Rated at over 80 watt; Recommended engraving speed: 100 - 500mm/s Recommended cutting speed: 1 - 30mm/s (actual speed depends on the thickness of material) Mechanics Linear System— Enclosed aeronautical aluminum rails Motion— Equipped with stepper X Y Z axis plus mechanical limit switches Cooling— easy-to-setup water pump and hoses Air Assist— Built-in air assist with no external compressor required Ventilation— On-board exhaust fan as well as an exhaust hose so you can vent the fumes to the outdoors Standard 110V AC power connection 4-pin port connection for rotary axis devices Temperature Recommended Operating Temperature: 60-104 °F (16C-40C) Attention: the water temperature must be maintained at 60-70°F (16-21°C) 80W la/ser tube with an estimated lifetime of up to 8 000 operation hours depending on power setting usage and water cooling performance PLEASE NOTE: Frequent use of high la/ser power settings will shorten the la/ser tube lifetime as follows: Low Power 10–40% = 7 000–8 000 Hours Moderate Power 40–70% = 5 000–6 500 Hours High Power 70–100% = 3 000–4 000 Hours Can safely engrave or cut any la/ser-compatible material Wood glass acrylic fabric leather paper cardboard rubber Contact us with questions on specific materials not listed. If necessary we can test it for you A Pair of la/ser Protective Glasses *1 la/ser Engraver Machine *1 Water Pump *1 Storage Tank *1 Ethernet to Ethernet Cable *1 USB Type-A to Type-A Cable *1 Venting Exhaust Duct (4 ft. max. length) *1 Water Hoses *2 USB Drive with Software (RDworks) *1 Hex Wrenches *10 Double-sided Tape *1 Power Cord *2 Accessory Bag *1 Keys *2 Silicone Sealant *1 Instruction Manual *1 Stainless Steel Clamp *1 2-year warranty on all 80W la/ser machines and parts 1-year warranty on la/ser tube FDA Approved & CE Certified
