Module Balanced Driver Board Balanced Vehicle Drive Brushless Motor Controller Controller Module

Label:Yes Package included:1Pc Brushless Motor Controller Module DC 12-36V 15A 500W Operating Temperature: -40 ~ 85°C Humidity: 90%RH Speed Voltage: 0.1V-5V Over-current protection: Yes Speed control signal: Yes Operating voltage: DC 12V-36V Steering control: Yes Enable Control: Yes Size: 63*42*17mm(L*W*H) Operating Current: 15A or less Driver Power: 500W or less Stall protection:Yes Power terminal Out: VCC(positive power supply) GND(negative one) MC(motor phases W) MB(motor phases V) MA(motor phase U) Set for the control side: [GND] control terminal ground [VR] the governor end 0-5V(corresponding to 10% of motor speed -100%) [ZF] reversing control(connected to 5V or ground can charge the motor rotation direction) [M] tachometer pulse output(depending on the number of motor poles corresponding to the number of pulse per revolution of the output number) [EL] enable control terminal(connected to 5V ot ground running then 5V, grounding the motor stops) [5V] 5V control terminal HALL for the hall terminals: [5V] Hall power positive [Ha]Hall signal [Hb]Hall signal [Hc] Hall Signal [GND]Hall negative Wiring: Control terminal for SET: 1. Available potentiometer system speed can also be connected to the MCU control, when the potentiometer control wiring, the potentiometer middle pin is connected to VR speed port, potentiometer connected to both ends of 5V and GND terminal voltage more high speed faster. 2. You can switch control can also be connected to the MCU control, to GND in one direction, then in one direction 5V. 3. Pulse speed signal: high and low output . IC can not understand the information with the customer request.
