Modbus RTU Gateway Real Time Wireless Communicator Monitoring System integrated Cloud Platform Support Modbus RTU over TCP S271
Technical Details
| Alarm Type: | SMS,Apps Control |
| Arming Type: | APP |
| Brand Name: | KING PIGEON |
| Communication Interface: | Wireless |
| Display: | No |
| GSM Remote Control Analog Inputs: | 4 Analog Inputs. 12 bit resolution, 0-5V or 0-20mA or 4-20mA |
| GSM Remote Control Digital Inputs: | 4 Digital input, NC/NO/Edge/Level type, Can be used as Pulse Counters; |
| GSM Remote Control External antenna: | SMA Antenna interface, 50 Ohm |
| GSM Remote Control Frequency: | 850/900/1800/1900Mhz |
| GSM Remote Control GPRS connectivity: | GPRS multi-slot class 10 |
| GSM Remote Control Relay Outputs: | 4, Rated |
| GSM Remote Control Serial Interfaces: | 1 USB Port; |
| GSM Remote Control SIM interface: | Supporting 3V SIM Card |
| GSM Remote Control TCP/IP stack: | TCP,UDP |
| Model Number: | S271 |
| Name: | Modbus RTU Gateway |
| Output Number: | 10 |
| Password Keyboard: | No |
| Power: | DC 12V/1.5A |
| Size: | 168mm*113mm*32.3mm |
| Video Interface: | No |
| Zone Number: | 4 |
