Mini SD-SDI HD-SDI 3G-SDI to AV Scaler Converter

The SDI to AV Scaler converter allows SD-SDI, HD-SDI and 3G-SDI signals to be shown on CRT or HDTV while ensuring high bit rates of 2.970Gbit/s to give you fast signal transmission without any loss. For professionals this means that it is now easier to distribute and extend your 3G-SDI signal while giving you the ability to display your work on TV thanks to the built in the converter. Furthermore, thanks to the loop-through 3G-SDI design, users are able to enjoy both SDI and AV at the same time.
Features
Operation at 2.970Gbit/s, 2.970/1.001Gbit/s, 1.485Gbit/s, 1.485/1.001Gbit/s and 270Mbits/s.
Equalized and re-clocked loop output.
Auto video mode detection (3G/HD/SD).
Conversion from SMPTE 425M level B to level A 1080p 50/59.94/60 4:2:2 10-bit.
Connect with other units to extend your signal over long distances.
Simultaneous display with SDI/AV signals.
Alternative audio output to analog 2CH.
Supports signal transmission distances of up to 300M for SD signal, 200M for HD signals and 100M for 3G signals.
HD signals and 100M for 3G signals.
Specifications
SMPTE Standard 425M Level A & B, 424M/292M/259M-C
Input Port 1 x BNC(SDI/HD-SDI/3G-SDI)
Output Port 1 x BNC (SD/HD/3G-SDI), 3 x RCA (CVBS, L/R)
SDI Transmission Rates 2.970 Gbit/s and 2.970/1.001 Gbit/s
SDI In/Output Resolution SD: 480i@60, 576i@50; HD: 720p@50/60 1080i@50/60; 3G: 1080p@24/25/29.97/30/50/59.94/60
CVBS Output Resolution PAL/NTSC-M
Power Consumption Max. 5W
ESD Protection Human Body Model ±8kV (air-gap discharge), ±4kV (contact discharge)
Dimension 10L x 6.5W x 2.5H cm
Weight 370g
Package included 1 x 3G-SDI to AV Scaler Converter, 1 x 5V DC Power Adapter
