Mini L293D Motor Driver Expansion Board Internal Diodes Overtemperature Protection

Manual Click here to openFeature L293D motor shield the input voltage DC4 5 25V 600mA output current capability per channel 1 2A peak output current non repetitive per channel Enable facility Overtemperature protection Logical 0 input voltage up to 1 5V High noise immunity Internal clamp diodesDescription The Device is a monolithic integrated high voltage high current four channel driver designed to accept standard DTL or TTL levels and drive inductive loads such as relays solenoides DCand stepping motors and switching power transistors To simplify use as two bridges each pair of channels is equipped with an enable input A separate supply input is provided for the L0GIC allowing operation at a lower voltage and internal clamp diodes are included This device is suitable for use in switching applications at frequencies up to 5 kHz Package includes 1 x L293D Motor Driver Expansion Board
