Mini Digital TV Stick Indoor SDR+DAB+FM DVB-T Tuner Antenna Wireless With Remote Control Receiver HDTV USB 2.0 Dongle St

Feature Sticks with this combination RTL2832 R820T are relatively new on the market The main difference to all the other supported tuners so far is that it uses a Low IF 3 57 MHz architecture instead of Zero IF That means the tuner is only connected to the In Phase ADC input and the internal down converter of the RTL2832 is generating the complex samples The advantage of this is that there is no DCoffset surge in the middle of the spectrumSo far the tuner driver comes straight from the kernel driver that Realtek supplies and setting gain manually is not supported yet although functions for that seem to exist There is still is a lot that needs to be done the best thing most likely would be to completely rewrite the driver or at least clean it up dramatically Initializing the tuner takes way too long at the moment since the driver produces a lot of I2C traffic most of it being redundant as it seems The driver originally had a frequency limitation of 40 MHz to 900 MHz but tests showed that the PLL of my stick can achieve lock up to 1766MHz and indeed both ADS B at 1090 MHz and L Band DAB at 1463 MHz as well as GMR at 1556 MHz can be received just fine with the R820T Also the PLL could lock again at 1850 MHz to 1860 MHz and the reception of a GSM 1800 BTS at 1854 MHz worked as well Some initial comparisons 1 between the E4000 and R820T seem to hint at the R820T being a bit more sensitive especially visible in the Tetra screenshots Given that the supply of
