Mingyiq 2pcs cylindrical mounting reed proximity switch normally open magnetic sensor

Details: Proximity sensors are made by molding and sealing a magnetic spring tube attached to the wire. Switching occurs when there is a magnetic object nearby. It is generally used as a position sensor and is widely used in measuring instruments office automation equipment household items security equipment and transportation equipment. Material: ABS and epoxy resin Simple installation and adjustment Panel Mount Sensor No need to wait for power Sealed design for long service life application: Position and limit detection switches security system door switch Maximum Contact Rating: 10w Maximum Switching Voltage: 100v DC Maximum switching current: 0.5A Minimum breakdown voltage: 200vdc Maximum carrying current: 1.0 a Maximum Contact Resistance: 100 MΩ Release time: 0.4 ms maximum. Operating time: 1.0 ms max. Diameter: 5.6mm Sensor length (excluding cable): 30mm Cable length: about 34cm 尺寸：6*30mm 6*25mm 6*20mm 5*25mm 4*18mm 4*15mm 6*15mm 5*15mm Package Included: 2 * Proximity switch
