Mingyiq 1PCS RTD PT100 Temperature Transmitter DC24V Minus 50~100 Degrees Output 0-10V

Describe Through the transmitter thermal resistance resistance signal can convert into 0-10V voltage signal convenient to use with computer. Other function description: 1. Built-in anti-reverse connection circuit output 0mA current when the power supply is reversely connected. 2. Built-in π-type EMI filter circuit surge absorption voltage of 36V can deal with most industrial field interference signals. 3. The terminal is made of copper nickel-plated stamping parts and the shell is made of engineering flame-retardant plastic. 4. Allowable wire resistance: ≤ 0.50 the mirror current source is used to compensate the deviation of the wire signal. When the wire resistance is greater than 1Q it will cause a large deviation in the measurement. 5. The analog multiplication circuit realizes the linearization of the platinums resistance signal and realizes the linear parameters of the output voltage and the nonlinearity is less than or equal to 0.05%. Specification Sensor: Pt100 Measuring range: -50~100℃ Output: 0-10V Operating voltage: DC 24V Accuracy: plus or minus 0.2 percent FS Dimensions: 45mm diameter (1.77inch) Colour: blue Material: Plastic Weight: 30g Package included: 1* temperature transmitter
