Mingyiq 1000Vphotovoltaic DCfuse holder for short circuit protection gpV of solar system

features: PV string fuse for solar panel - 1000VDC A series of fuses in a 10x38mm package specially designed to protect and isolate PV strings. The DC fuse can interrupt the low overcurrent associated with the faulty PV (reverse current multi-array fault) string array. application Solar panel solar photovoltaic DC string. Recommendation: Always use fuses on the positive and negative terminals of any PV string with rated voltage up to 1000VDC Specifications: Electrical characteristics Rated voltage 1000VDC Ampere 6A 10A 15A 20A 25A 30A Rated braking capacity 33kA dc Minimum interruption rating 1.3x In Time constant below 1ms Package includes: A: 1 * Base (without indicator light) B: 1 * Base (with indicator light) C: 1 * Fusible core
