Micsig AC/DC Current Probe CP2100A 800KHz 10A Maximum Measurable Current 100Apk 70.7Arms (DC+ACpk)

Safety Precautions:1.The measuring circuit should be CAT II 600V or below.? Do not measure bare conductor.2.Do not touch the conductor under test and the sensor head whileизмерения.3.Do not operate in wet / damp conditions.4.Do not touch the instrument or the object under test with wet hands.5.Please use this product within the scope permitted by the terminal.6.Please use this product as required.? Please ground the product through the USB power cable. Технические характеристики:Version: 1.0Modify content: First releaseRelease time: 2019.05Parameter: CP2100A Bandwidth: DC ~ 800KHz (CP2100A) Rise time: ≤583ns (CP2100A)Ranges: 10A / 100A (Optional on the switch)Output sensitivity: 0.1V / A (10A) /0.01V/A (100A)DC accuarcy (typical): 3% ± 50mA (10A) / 4% ± 50mA (100A, 500mA ~ 40Apk)/ 15% (100A, 40Apk ~ 100Apk)Signal delay: DC signal linearity (typical): DC signal linearity, typical on page 6Measuring range: 50mA ~ 10Apk (10A) / 1A ~ 100Apk (100A)Maximum measurable current: 100Apk, 70.7Arms (DC + ACpk) / 200Apk-pk, 70.7Arms (AC)Maximum working voltage: CAT III 300V CAT II 600VMaximum float voltage: CAT III 300V CAT II 600VMaximum conductor diameter: 13mmOverload indication: The buzzer beeping, the button light flashingPower supply: DC 5VProbe head size: 11 * 6.1 * 2.5cmControl box size: 10.8 * 5.6 * 2.6cmLength: 228cmWeight: 290gSingle package weight: 1000gSingle package size: 29.5 * 23.6 * 5.7cmРабочая температура: 0°С ~ 50°СStorage Temperature: -20 ° C ~ 80 ° COperating Humidit
