Micro PA100 HF Power Amplifier 100W Shortwave 3.5MHz-30MHz QRP Portable Base Automatic TX RX Dual Cooling System Low Pas

Features 1 Micro PA100 100W portable base shortwave power amplifier 2 High speed automatic TX RX switching with RF sensing works even without PTT SEND connection 3 Fast automatic LPF Low Pass Filter switching no need for ACC control cable 5 sets of 5 stage LPFs cover all HAM shortwave communication bands from 80m to 10m 4 Power and SWR Standing Wave Ratio display with protection ensures safe operation even with poor antennas preventing damage 5 Wide voltage range with voltage display and protection convenient for outdoor use with lithium battery power supply 6 Temperature display and thermal protection with intelligent dual fan cooling 7 Semi insert mode allows flexible operation even without PTT SEND connection 8 Supports for ICOM YAESU and XIEGU band switching protocols ACC control cable required Specifications Frequency Range 3 5MHz 30MHz Input Power 1 5W maximum 7W Output Power 100W ±1 5dB at 13 8V Output Impedance 50Ω Power Supply Voltage 10V 15V typical 13 8V Note Lower voltage will result in lower output power Current Consumption ≤18A Operating Temperature ≤55°C Dimensions 125mm 51mm 180mm excluding protrusions 132mm 58mm 198mm including protrusions Weight About 1 1kg Warranty One year free warranty included Package Included 1 x HF Power Amp1 x Power Cable Attention Due to cost constraints the front panel decorative frame is 3D printed with the default material being PETG HF filament from Bambu Lab Ple
