Mega +WiFi R3 ATmega2560+ESP8266 32Mb USB-TTL CH340G Development Board Robotdyn for Arduino - products that work with of

Feature Supply Voltage 7 15V recommindModel Number MEGA WiFi R3 AT2560 ESP8266 CH340Gis customized YesMCU ATmega2560WiFi MCU ESP8266USB converter CH340GPinOut U no MEGA R3 Description Full integration on one board Mega R3 ATmega2560 and WiFi ESP8266 with memory 32Mb megabit All of the modules can work together or each separately And everyone has their own pinout headers The convenient solution for the development of new projects requiring U no and WiFi Via USB you can update sketches and firmware for ATmega2560 and for ESP8266 For this on board have the USB serial converter CH340G Use this board is very simple The board has DIP switch to connect the modules For example to USB and ATmeg2560 USB and ESP8266 ATmega2560 and ESP8266 Table DIP switch 12345678CH340 connect to ESP8266 upload sketch OFFOFFOFFOFFONONONNoUSECH340 connect to ESP8266 connect OFFOFFOFFOFFONONOFFNoUSECH340 connect to ATmega2560 upload sketch OFFOFFONONOFFOFFOFFNoUSECH340 connect to Mega2560 COM3 connect to ESP8266ONONONONOFFOFFOFFNoUSEMega2560 ESP8266ONONOFFOFFOFFOFFOFFNoUSEAll modules work independentOFFOFFOFFOFFOFFOFFOFFNoUSEDocuments Manual Click here to openDimensional drawing Click here to openPinout Click here to openSchematic Click here to openDrivers Click here to openPackage includes 1 x Module
