Mayatech MT900 902-928MHz 40km Long Range Aerial Survey FPV Transmitter Module Compatible PIX 3DR Ground Station for RC

Description The Mayatech MT900 is a high performance ISM band wireless modem Operating frequency range 902 MHz928 MHz It is a communication device that can be used for long distance data transmission This device has been used in Autopilot APM and paparazzi Specifications Brand Name MayatechItem Name MT900Version Only MT900 module MT900 Combo optional Operating Frequency Range 902 928MHzOutdoor ZUI Large Communication Distance 40km transmit power adjustable Operating Temperature 40℃ 85℃RF Port RP SMACommunication Port RS 232 interfacePower Port 5V 800mA peak maximum transmit power I O 6 General Purpose I O Digital ADC PWM RF Output Power 1W 30 dBm which can be increased or decreased by 1dB through software Over the air Data Transfer Rates 4 8 16 19 24 32 48 64 96 128 192 and 250 kbit sec 64K 128K default Receive Sensitivity 121 dBm at low data rates high data rates TBA Size 30x57X12 8mmWeight 15g single moduleFeatures Dual antenna design automatically switches one of the antennas based on signal quality Low pass filtering with low pass amplifier with greater than 20DB Data air transmission rate up to 250kbps Support dual antenna Package Included 1x Mayatech MT900 Moduleor2x Mayatech MT900 Module4x Antenna1x Connecting Cable 1x Data Cable
