Mavis Laven Bicaquu AD8130 Module High Speeds Difference To Single-Ended Amplification ADC Driver High CMMR

Features: 1. 100% brand new and high quality. 2. High CMMR(common-mode rejection ratio). 3. Low noise low distortion with good signal transmission capability. 4. Adjustable amplification gain. 5. Built-in power saving mode. Specification: High Speed: 270MHz 1090V/us (G=+1) CMMR: 94dB(MIN DC to 100kHz) 80d(MIN 2MHz) 70dB(10MHz) Input Impedance: 1MΩ difference Noise: 12.5 nV/Hz Common-Mode Input Range: ±10.5 V Distortion 1Vpp(5MHz): -79dBc(worst harmonic 5MHz) Gain: G = +1 no external components required Power Supply: +4.5V - ±12.6 V Weight: Approx. 12g Package List: 1 * ADC Driver 1 * Cable
