Matte Panel Speed Controller Durable US-52 Speed Controller Printing For Packaging Electronics Food 180W 200W 250W

Matte Panel Speed Controller Durable US-52 Speed Controller Printing For Packaging Electronics Food 180W 200W 250W Specification: Item Type: Speed ControllerBrand: BERMModel: US-52 Working Voltage: AC220V 50/60HZ voltage fluctuation range is ±10%Ue Matching Motor Power: 180W / 200W / 250W optional Operating Environment: -10 ~ +50 degrees Celsius Relative Humidity: Less than 90% Speed range: 90-1400r/min 50HZ 90-1700r/min 60HZ Explanation: The governor has 6 wires the black wire is the main motor wire the red and white are the capacitor auxiliary wires the 2pcs blue wire are the speed feedback wires and the green wire is the ground wire. Instructions: 1. Turn off the power connect it according to the wiring diagram and confirm that the wiring is correct do not modify it arbitrarily 2. Fix the controller and adjust the speed to the lowest 0 to avoid the instantaneous high current when starting the power supply causing permanent damage. 3. Then turn on the power again and adjust the speed knob to the desired position. Turn off the power when not needed; 4. When the governor is connected to the motor if you find that the torsion or speed does not meet the requirements please adjust the trimmer potentiometer on the side of the product speed setting adjustment 5. If you want to change the running direction of the motor just change the CCW and CW jumpers on the terminal block on the back of the controller. Select COM and CW short circuit then the motor will rotate CW Select COM and CCW short circuit then the motor will rotate CCW When changing the direction wait for the motor to stop completely before changing. 6. The action switch only controls the movement or stop of the motor. It is not used for power interruption. Please turn off the power if it is not used for a time. Application: It is widely used in packaging printing food electronics instrumentation and clothing industry production lines as speed-regulating drive devices. Package List: 1 x Speed Controller
