Matek System 20x20mm F411-mini Mini F4 Flight Controller AIO OSD BEC and LED Strip for RC Drone
Description
Matek System 20x20mm F411-mini Mini F4 Flight Controller AIO OSD BEC and LED Strip Connection Guaid Specification: Brand Name: Matek Item Name: 20x20mm Mini F4 Flight Controller AIO OSD BEC and LED Strip MCU: 100MHz STM32F411 IMU: MPU6000 OSD: BetaFlight OSD w/ AT7456E chip Camera control supported on Rssi pad Battery Voltage Sensor: 1:10 Current Sensor: No (FCHUB-A option) BEC: 5V 2A LDO 3.3V: Max.300mA I2C1 SDA & SCL available WS2812 Led Strip : Yes Built in inverter for SBUS input (UART1-RX) PPM/UART Shared: UART2-RX SoftSerial supported on S5 & S6 Beeper : Yes RSSI: No Blackbox: No Size: 28x28mm Mounting Hole: 20x20mm Weight: 4.5g Features: - 20x20mm Mounting hole, only 4.5g - with betaflight OSD and 5V BEC output - with 2 LED indicator, blue and red - Built in inverter for SBUS input (UART1-RX) - PPM/UART Shared: UART2-RX Package Included: 1x F4 Flight Controller 6x Silicon grommets M4 to M3 6x Brass grommets M3 to M2
