Marshall Electronics QVW-1708-3G 6RU 17" 3G-SDI Quad View LED Desktop Monitor
The QVW-1708-3G is part of Marshall Electronics' Quad Viewer series of rack mount monitors which can function as a single display supporting inputs up to 4K or four separate displays in Quad View mode supporting inputs up to 1920 x 1080 in each quadrant. Convenient, intuitive front panel controls in addition to control via network Quad 3GSDI inputs with active loop-through and auto format detection The QVW-17083-3G can be mounted in any standard EIA 19-inch equipment rack. The attached rack ears can be angled to provide the user control over the viewing angle. A VESA standard 75mm hole pattern also allows custom mounting installations. 1920 x 1080 Native Display (16 x 9) Accepts Input Resolutions Up to 4096 x 2160 IMD - In Monitor Display Functions Area Markers Hard Tally + Soft Tally Network Control via Ethernet Presence indicators for TC, CC (608/708), Audio Bar Display for Embedded Audio, also Timecode Display RS-485 in/out/host ports allow daisy-chaining IMD and display functions Pixel-to-Pixel Mode Compatible with CalMAN 5 Calibration Technology IMD Control via Ethernet or RS-485 serial data Status Display Shows True Format / Frame Rate Rack Ears Included In-field firmware update Quad-Viewer Feature Allows viewing of 4 inputs on the screen at once. Each input source is scaled and positioned in real-time so that all 4 inputs can be seen. Besides the standard Quad layout, there are 3 other layouts including Full Screen.
