Marani DPA2655QR 2 Input & 6 Output Speaker Management System with Matrix Mixer

The Marani DPA2655QR 2 Input and 6 Output Speaker Management System with Matrix Mixer is Designed for maximum versatility, it provides all the processing and control necessary for both live and fixed installation use. Providing for any crossover configuration, it offers 2 analog inputs, 6 analog outputs and a digital S/PDIF input, managed by a powerful DSP Engine, in addition to high performance 24Bit AD/DA Converters. Each input channel provides a choice of EQ with 5-band Parametric equalization, Gain control and configurable Delay. Each output offers up to 5-band of parametric equalization, in addition to the crossover filters which themselves provide slopes from 6dB/Octave up to 24dB/Octave. Each output path also features RMS Compressor, Peak Limiter and configurable Delay. The DPA2655QR supports a full matrix mixing mode where inputs may be routed/mixed in any ratio to any output. For remote configuration and control the DPA2655QR can be connected via USB or Ethernet. The control remote PC software allows simultaneous control up to 32 units, setting all parameters and showing real time levels. Outstanding Performance Excellent sonic performance with 24bit high end converters coupled with 48kHz sample rate 2 inputs, 6 outputs with full matrix mixing Top-grade DSP Engine 5 band parametric equalization per input channel 5 band parametric equalization per output channel Each band can be switched to Bell, Low/High Shelving, Low/High-Pass, All-Pass, Band-Pass and Notch Low/High Shelving, Low/High-Pass, can be selected as 1st and 2nd order, variable Q response Crossover filters with slopes from 6dB/Octave up to 24dB/ Octave including Butterworth, Bessel, Linkwitz-Riley and customizable topologies Each output features a precision dynamic range controller composed of a Peak Limiter and a RMS Compressor with selectable ratio and variable knee Adjustable Delay time up to 850 ms for every input and output channel Phase correction per output channel Direct PC/Network Connection Front panel USB connector for direct PC communications Ethernet interface for system setup, monitoring and control via fully manageable remote PC software Control Front panel interactive LCD display for local access and configuration Front panel 7-LED level meter indicators per channel Simultaneous control up to 32 units via PC software Up to 64 storable user presets Security Lockout.
