Mahr 2191800 10 Micro Pocket Surf IV EGH-1019 Portable Surface Roughness Gage

Pocket Surf IV EGH-1019 Portable Surface Roughness Gage The NEW Mahr Pocket Surf IV EGH-1019 Portable Surface Roughness 10µ m. Surface parameters include Ra Ry Rmax Rz. While the new Pocket Surf IV looks virtually the same as when it was introduced over 30 years ago it contains updated electronics and employs significant product use improvements. Some of the improvements include: Ability to view the three parameter results with one measuring cycle; Digital calibration which eliminates the manual screwdriver and potentiometer calibration process; New output connector providing three cable formats and MarCom compatibility. Features Pocket-sized economically priced completely portable instrument which performs traceable surface Roughness measurements on a wide variety of surfaces Its can be used confidently in production on the shop floor and in the laboratory Solidly built with a durable cast aluminum housing to provide years of accurate reliable surface finish gaging Can be used to measure any one of four switch-selectable parameters: Ra Rmax/Ry Rz Selectable traverse length 1 3 or 5 cut-offs of 0.8 mm/.030 Operates in any position horizontal vertical and upside down Four switchable probe positions axial (folded) or at 90° 180° or 270° Even difficult-to-reach surfaces such as inside and outside diameters are accessible Easy to read LCD readout presents the measured roughness value in microinches Micrometers within half a second after the surface is traversed MarConnect data output for easy SPC-processing that is compatible with the most common data processing systems Out of range (high or low) and battery low signals are also displayed Improved battery life with easy to replace standard 9V batteryDetails: PMD-90101 Certified Specimen incl. Test CertificateSpecifications Size: 10 µ m Resolution: Probe 90 deg 10 m radius Graduation: 0.01 µ m / 1 µ in Type: Ra Ry Rmax Rz Site Sort: 131 Accuracy: Meets ASME-B46.1 ISO DIN standards and MIL specifications - SKU: QLLR1804
