Machifit Pneumatic Connector Quick Joint PC Straight Male Thread Pipe Fittings 8-01/02/03/04

Description Machifit Pneumatic connector quick joint PC straight male thread pipe fittings 8 01 02 03 04 fit for extruder Specification BrandMachifit Material BrassTypePC Male thread Pipe Size8 01 8 02 8 03 8 04 mm Outside diameter of inserted tube8mmThread diameter01 G1 8 9 7 mm02 G1 4 12 7 mm03 G3 8 16 mm04 G1 4 20 mmPressure resistance0 1MPaWorking pressure10KGAmbient temperature 20 60℃Use fluidAirApplicable hosePU pipe PE pipe and nylon pipeScope of applicationAutomation equipment Mechanical medical textile equipment food processing Tripping when the tripper is pressed it can release the tube which is locked by the latch spring Fastening spring suitable for polyurethane pipe nylon pipe with great grasping force Sealing ring high quality sealing ring can be used for low vacuum 0 1 Pa and 1MPa pressure Special groovesensure airtightness at the time of tube insertion while long low insertion resistance Ring used to fix plastic sleeve with a large fixed stand Fastening sleeve the upper end is tightly connected with the silver ring and the locking spring is fixed Quick joint installation 1 Before installation confirm the correct model and size and confirm the product crack and scar 2 The length of the connecting pipe should be left as the pressure changes 3 The pipe of joint box is not allowed to be pinched stretched and bear negative torque to avoid joint damage pipe damage rupture or fall off 4 For screw threads of pipe
