Machifit GM4058-BLDC3650 DC 24V Rated Speed 30RPM Brushless Worm Geared Reducer Motor

Description MachifitGM4058 BLDC3650 DC 24V Rated Speed 30RPM Turbo Brushless Motor Worm Geared Reducer MotorSpecifications Material MetalVoltage DC 24 0VInput voltage V 24Retarder Reduction Ratio1 108No Load Speed RPM 60No Load Current mA ≤200Rated torque kg cm 30 0 Kg cmRated Speed RPM 30Rated Current A ≤1 0Max Torque60 Kg cmUnload Current A 3 0WeightAbout 386gQuantity1pcWarning power plus or minus pole fault power supply and negative pole touch FG line will damage the drive board resulting in damege to the motorBLDC3650 five line connection mode 1 black line power blue line is connected to the negative pole motor immediately brake 2 red wire power 3 white line CW CCW communication line the white line and black line connection to change the steering 4 yellow line FG signal line output Holzer signal based on the oulse of a ring signal 5 blue line PWM pause width modulatiuon line can be connected to 0 5Vpulse width governor BLDC3650 speed regulation connection method Note speed regulation power supply and motor power supply is indepemdent 1 in the PWM speed control interface input amplitude is 5V the frequency of the PWM signal 10K 2 when the duty ratio of is less than 10 2 trhe motor is in a static state 3 duty cycle adjustment by 10 100 corresponding to the motor speed form the lowest to the highest 4 connection line is connected to trhe blue PWM governor middle tripod feet 5 with the motor power supply common ground black motor lin
