Machifit GA12BY15 DC 5V 30RPM 15RPM 5RPM Stepper Motor Gear Motor with All Metal Gearbox

Description: MACHIFIT GA12BY15 DC5V 30RPM 15RPM 5RPM stepper motor gear motor with all-metal gearbox. Specification: Model GA12BY15 Voltage DC 5V Output Shaft Diameter 3mm (D-type: 2.5mm) Output Shaft Length 10mm Gearbox Length see the table Wiring (Phase) Yellow: A Green: A- Red: B Black: B- BY15 Motor without Gearbox Electrical Characteristic: Rated Voltage DC5V Coil Resistange 1010% Number of Phase 2 Phase Step Angle 18/step Excitation Method 2-2 Phase Exciting Drive Mode Bi-Polar Drive Current Per Phase 300mA/Phase Max Pull Torque 6.0gf*cm Min(500PPS, 5V DC) Pull Out Torque 7.0gf*cm Min(500PPS, 5V DC) Max. Starting Frequency 800PPS Min Max. Response Frequency 1000PPS Min Insulation Class E Class Insulation Strength 100V AC, 1S Insulation Resistance 1M(DC100V) Main Parameter: Voltage Gear Rated No load Load torque Stall speed cureent speed cureent torque(g.cm) cureent torque(kg.cm) 5V 1:298 5rpm 300mA 5rpm 350mA 1000 400mA 2.00 1:100 15rpm 300mA 13rpm 350mA 350 400mA 0.70 1:50 15rpm 300mA 27rpm 350mA 180 400mA 0.35 Package Included: 1 x GA12BY15 Stepper Motor More Details:
