Machifit ER32 5/8 Inch Spring Collet Chuck Collet For CNC Milling Lathe Tool

Description Machifit ER32 5 8 spring collet chuck collet fits for CNC milling lathe tool Specification ModelER32Precision0 001mmMaterialSpring SteelGripping Range5 8Upper Diameter35 mmBottom Diameter25 mmHeight40 mmQuantity1 pcSuitableCNC seriesHardness46Features 1 High Accuracy and ease of operation 2 Use good quality Carbon steel after heat treatment has good flexibility and abrasion resistance 3 The clamping force high accuracy good gripping stability 4 Can be for gripping the drill boring knife chisel reamers and other tools 5 Ground roughness is Ra0 4 Microns plus overall fine polish 6 Suitable For Boring milling drilling tapping engraving CNC spindle machines and other processing 7 T I R 0 0003 or 5um In order to make all collets running true on your side make sure your machine spindle and chuck holder running true on my side Ill make sure all those collets running in tenth The correct methods of mounting the collet nut 1 Put the chuck into the pressure cap gently turn the clamp spring when eccentric portion of the pressure cap recessed clamp spring groove Along the arrow direction and use equal force to push clamp spring can mount pressure cap 2 Put the clamp spring and cap all together installed on the chuck body or spindle Insert into the clamping hole after wipe the cylindrical shank use a wrench to tighten the pressure cap until clip firmly the tool before use Package Included 1 x ER32 Collet More Details
