Machifit 10pcs ER32 20mm Spring Collet Collet Chuck for CNC Milling Lathe Tools

Description Machifit ER32 2 20mm Spring Collet Collet Chuck for CNC Milling Lathe ToolsSpecification ModelER32Material20MnHardnessHRC56 60Taper degree16 degreeTotal height40mmOuter diameter Max 32mmGripping Range20mmQuantity10pcs Features It is ER32 precision spring collet Widely used in boring milling drilling tapping CNC sculpture and other processing operations also can be supported used with the holder of CNC tool Big clamping force wide clamping range high accuracy The correct methods of mounting the collet nut 1 Put the chuck into the pressure cap gently turn the clamp spring when eccentric portion of the pressure cap recessed clamp spring Along the arrowdirection and use equal force to push clamp spring can mount pressure cap 2 Put the clamp spring and cap all together installed on the chuck body or spindle Insert into the clamping hole after wipe the cylindrical shank use a wrench totighten the pressure cap until clip firmly the tool before use Note Avoid fastening pressure cap that not installed tool to avoid damage the clamp spring 3 Use a wrench to loosen the pressure cap and took out the chuck or tool remove the tool Along the direction of the arrow push out the clamp spring Then according to need replace other clamp spring Note Please note that the packge inlcuded 1pcs collet only Package Included 10 x ER32 ColletsMore Details
